Patient Monitors

Contec 2 para patient monitor adopts Oscillometry for NIBP measuring, Photoelectric Oxyhemoglobin Inspection Technology combining Capacity Pulse Scanning & Recording Technology for SpO2 measuring. Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MAP), SpO2 and Pulse rate(PR) can be accurately measured. Compact appearance, comprehensive functions, simple and convenient operation, which is applicable for hospitals, community medical treatment and family.

Key Features of Contec 2 para patient Monitor :

• Contec 2 para patient monitor is applicable for adult, pediatric and neonatal for all-round monitoring, easy operation and high cost performance.
• Be applicable for medicine, surgery, operating room, ICU/CCU, emergency room, obstetrics and gynecology, pediatrics.
• Built-in rechargeable Li-polymer battery for uninterrupted monitoring.
• Compact and flexible appearance, easy for carrying and be suitable for indoor and outdoor(in ambulance) monitoring.
• With user-friendly interface.
• Display with 2.8” (320×240) color TFT LCD and red and yellow highlight LED.
• Visual and audible alarm for Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MAP), SpO2 and Pulse rate(PR), and upper and lower limit of alarm can be set.
• Unique Flash memory, storage for up to 2000 NIBP data and, 78000 SpO2 data.
• Convenient and quick in inquiring measurement data, review for NIBP trend graph within 24-hour and SpO2 and Pulse rate(PR) trend graph within 20-hour.

Alarms

Visual and audible alarm for Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MAP), SpO2 and Pulse rate(PR), and upper and lower limit of alarm can be set.

In the Box

Contec 2 para patient monitor, A SpO2 probe for CMS5100, An adult NIBP cuff, An extending tube for blood pressure, A power cord, A power adapter.

List of supplies with Contec 2 para patient monitor :

• SpO2 Sensor
• NIBP Cuff (Adult) with cable
• Power Cable and power adapter
• User Manual

Contec CMS 5100 measures NIBP, Spo2 and PR, and it is a vital sign monitor. It is applicable for adult, pediatric and neonatal for all-round monitoring. Due to its compact size, this Contec vital sign monitor is easy to carrying and suitable for indoor and outdoor monitoring.

Contec CMS 5100 patient monitor is having 2.8”  TFT/ LCD screen with real-time data and waveform. It can simultaneously display full monitoring parameters. Contec CMS 5100 can monitor and display SpO2, PR, NIBP parameters. Contec CMS 5100 patient monitor’s rechargeable internal battery brings a lot of convenience for patient monitoring.

Key Features of Contec Vital Sign Monitor, CMS 5100 :

• Be applicable for adult, pediatric and neonatal for all-round monitoring


• Easy operation


• Be applicable for medicine, surgery, operating room, ICU/CCU, emergency room, obstetrics and gynecology, pediatrics.


• Built-in rechargeable Li-polymer battery for uninterrupted monitoring.


• Compact and flexible appearance, easy for carrying and be suitable for indoor and outdoor(in ambulance) monitoring.


• With user-friendly interface.


• Display with 2.8” (320×240) color TFT LCD and red and yellow highlight LED.


• Visual and audible alarm for Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MAP), SpO2 and Pulse rate(PR), and upper and lower limit of alarm can be set.


• Unique Flash memory, storage for up to 2000 NIBP data and, 30000 SpO2 data.


• Convenient and quick in inquiring measurement data, review for NIBP trend graph within 24-hour and SpO2 and Pulse rate(PR)


• Trend graph within 20-hour.

Alarms

Visual and audible alarm for Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MAP), SpO2 and Pulse rate(PR), and upper and lower limit of alarm can be set.

In the Box

Contec patient monitor CMS 5100, A SpO2 probe, An adult NIBP cuff, An extending tube for blood pressure, A power cord, A power adapter

More details of about parameters of Contec CMS5100 patient Monitor :

NIBP monitoring

• Measurement method: Oscillometry


• Measurement mode: manual/auto/continuous.


• Auto measurement interval: adjustable from 1 to 90 minutes.


• Resolution: 1mmHg.


• Accuracy: Maximum Mean deviation≤±5mmHg, Maximum Standard deviation≤8mmHg.


• Self-check function.


• Overpressure protection: double protection for software and hardware.

Pressure Range :

For Adult:

• Systolic pressure: 40mmHg~270mmHg


• Mean pressure: 20mmHg~235mmHg


• Diastolic Pressure: 10mmHg~215mmHg

For Pediatric:

• Systolic pressure: 40mmHg~200mmHg


• Mean pressure: 20mmHg~165mmHg


• Diastolic Pressure: 10mmHg~150mmHg

For Neonatal:

• Systolic pressure: 40mmHg~135mmHg


• Mean pressure: 20mmHg~110mmHg


• Diastolic Pressure: 10mmHg~100mmHg

SpO2 monitoring

Continuous real-time measuring.

• Adopt digital SpO2 technology, which has strong anti-interference capability.


• Real-time display SpO2, pulse rate, SpO2 Plethysmogram, bar graph, SpO2 and Pulse rate(PR) trend graph.


• Standard finger-clip probe for adult , binding probe for neonatal is optional.

SpO2 Measuring

• Range: 35%~100% (Resolution: 1%)


• Accuracy: ±2% in stage of 70%-100%, and unspecified in stage of less than 70%.

Pulse Rate Measuring

• Range: 30bpm~250bpm(Resolution: 1bpm)


• Accuracy: ±2bpm or ±2%, whichever is greater.


• Measurement Performance in Weak Filling Condition: SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%, SpO2 error is ±4%; the Pulse rate error is ±2bpm or ±2%, whichever is greater.


• Resistance to surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.

A light weight, compact and portable Multi Parameter Patient Monitor (8.4″) (3 Para/5 Para) features high resolution color TFT display and is suitable for Arrhythmia analysis and S-T segment analysis in neonatal, paediatric and adult patients. Further, this features 72 hours graphic and tabular trends of all parameters on the touch screen monitor with great level of accuracy.

NIBP:

• Method Oscillometry


• Modes Manual / Auto / Continuous


• Auto Measure time Adjustable


• Measurement range 10-270mmHg

ECG:

• Lead Mode 3-Iead Or 5-lead


• Lead Selection I, II, III, avR, avL, avF, v


• Heart rate range Adult: 15-300bpm, pediatric /


• Neonatal 15-300bpm


• ECG waveform 2 channels


• Accuracy ±1 bpm or±1 %, Whichever is greater


• S-T segment detection: Measurement range 0.2mv~2.0mv

Specifications:

• Alarm Yes, audible and visual alarm, alarm events review


• High resolution 12.1” or 8.4” color TFT display


• Lightweight, compact and portable


• ECG, SPO2, NIBP, RESP, 2-TEMP, PR


• Built-in rechargeable lithium battery


• ECG waveforms of 7-leads display on the same screen


• +72-hours graphic and tabular trends of all parameters


• 72 alarm events of all parameters recall


• 32 seconds full-disclosure waveform review


• 500 NIBP measurement data can be stored and recall


• Data and waveforms color can be adjustable


• Arithmetic analysis and S-T segment analysis


• Suitable for adult, pediatric and neonatal patient

SPO2:

• Measurement range 0-100%


• Accuracy 70-100%, ±2% 0-69%, unspecified

Pulse Rate:

• Range 20-254 pm


• Accuracy ±3bpm

Respiration:

• Method RA-LL impedance


• Range Adult: 0-120 rpm;pediatric/neonatal: 0-15 rpm


• Apnea alarm yes

CMS8000 patient monitor has very useful features that can be used for ICU clinical monitoring with adult, pediatric and neonate patients. Medical staff may select different parameter configurations according to different requirements.

Contec CMS 8000 is having 12.1” color TFT/ LCD screen with real-time data and waveform. It can simultaneously display up to eight-channel waveform and full monitoring parameters, equipped with an optional 48 mm thermal recorder. The CMS8000 Patient monitor can be connected to the central monitoring system via a wired or wireless network to form a network monitoring system.

CMS 8000 can monitor and display ECG, HR,  SpO2, PR, RESP, NIBP and dual-channel temperature parameters. Dual IBP and ETco2 parameters are optional. Contec CMS 8000 integrates parameter measurement module, display and recorder in one device to form compact and portable equipment. Contec patient monitor cms8000’s replaceable internal battery brings a lot of convenience for patient moving.

Key Features of Contec Multipara Patient Monitor CMS 8000 :

• 12.1” Color TFT/ LCD, multi-language interface.


• Parameters:  ECG, SPO2, NIBP, RESP, Dual Temperature, PR


• Optional: Dual IBP, ETCO2, And the thermal printer


• Suitable for adult, pediatric and neonatal patient


• With the standard interface, oxygen graph, trend graph, big character interface and view bed, convenient to observe.


• Finish all operations with keys and knobs.


• Maximum 8-channel waveform synchronous display.


• Built-in rechargeable lithium battery


• Alarm: Yes, audible and visual alarm, alarm events review


• 72-hours graphic and tabular trends of all parameters


• 72 alarm events of all parameters recall


• 32 seconds full-disclosure waveform review


• 500 NIBP measurement data can be storage and recall


• Date and waveforms color be adjustable


• Arrhythmia analysis and S-T segment analysis


• Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of weak filling.


• Heart rate variability (HRV) analysis function


• NIBP measurement mode: Manual/AUTO/STAT, storage for 4800-group NIBP data.


• Review for 71 alarm events of all parameters and 60 arrhythmia alarm events.


• Drug concentration calculation and titration table functions.

In the Box

Cms 8000 monitor, ECG Cable, SpO2 Sensor, NIBP Cuff (Adult) with cable, Temperature Sensor, Power Cable, User Manual

CMS 9000 patient monitor can measure multi parameters such as ECG, RESP, SpO2, PR, NIBP and dual-channel TEMP, etc. It integrates parameter measurement module, display and recorder in one device to form compact and portable equipment. At the same time, CMS 9000 patient monitor’s built-in replaceable battery provides convenience for patient moving.

Key features of CMS 9000 patient Monitor :

• 12.1” TFT color LCD


• All-round monitor for adult, pediatric and neonates.


• With the standard interface, OxyCRG, trend chard, big character interface and view bed, convenient to observe.


• Waveform, parameter color and location can be set optionally.


• Operation mode: keys and buttons.


• Display up to 8-channel waveform on one screen.


• Display 7-lead ECG waveform on one screen, and with ECG step function.


• Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of weak filling.


• NIBP measurement mode: Manual/AUTO/Continuous, storage for 4800-group NIBP data.


• Review for 71 alarm events of all parameters and 60 arrhythmia alarm events.


• Drug concentration calculation and titration table functions.


• Print trend table data with one key.


• AC/DC, built-in rechargeable lithium battery achieve uninterrupted monitoring.

In the Box

CMS 9000 patient monitor, ECG Cable, SpO2 Sensor, NIBP Cuff (Adult) with cable, Temperature Sensor, Power Cable, User Manual

Yonker IE series is a patient monitor designed for transport situation. IE8 is a multi-parameter patient monitor designed and developed for ambulance monitoring, which with cheap price and easy to operation.

Optional configuration: Recorder, mobile trolley, balance arm

Application: Yonker IE8 patient monitor is suitable for patient transfer, ward round, community hospital, etc.And suitable for neonates, children, adults, the elderly and other kind of people.

Features :

• 3 parameters ( SPO2, NIBP, PR )
• 8 inch TP touch screen, waterproof level: IPX2
• Compact and small. Convenient for transport use
• Equipped with a simple bracket for easy use on the desktop
• With 12V-2A adapter
• Anti-fibrillation, anti-high-frequency electrosurgical interference
• Support diagnosis, monitoring, surgery three monitoring modes
• Support wire or wireless central monitoring system
• Audio / visual alarm, more convenient for doctors to observe the patient status
• Automatic data storage function: supports nearly 96 hours of historical monitoring data query
• Built-in high capacity lithium battery (4 hours) for emergency power outage or patient transfer.

The Yonker YK-8000C Multipara Patient Monitor is the perfect device for nurses and other medical professionals who need to keep track of a patient’s vital signs. With its 12.1-inch TFT screen, it provides a clear display of all ECG, RESP, SPO2, NIBP, PR, TEMP, IBP, ETCO2 data.

Features :

• 8 parameters (ECG, RESP, SPO2, NIBP, PR, TEMP, IBP, ETCO2)+ Fully independent module (Independent ECG + Nellcor     +  Suntech blood pressure + dual IBP);
• 3 level audio/visual alarm function;
• 12.1 inch color LCD touch screen supports multiple language modes;
• Built-in high capacity lithium battery (4 hours) for emergency power outage or patient transfer;
• Automatic data storage function: supports nearly 96 hours of historical monitoring data query;
• Anti-fibrillation, anti-high-frequency electrosurgical interference, support diagnosis, monitoring, surgery three  monitoring modes, support wire or wireless central monitoring system;
• Optional printing function, suitable for operating room, ward and other scenes.

Standeard Parameters :

NIBP :

• Method: Oscillometry
• Measure mode: Manual, Auto, STAT
• Measure interval in auto mode :  1~5/10/15/30/60/90/120/180/240/480 min
• Measure period in STAT mode : 5 min

Pulse rate range: 40 ~ 240bpm

Measure & alarm range:

Adult :

• SYS 40 ~ 280mmHg
• DIA 10 ~ 220mmHg
• MEAN 20 ~ 240mmHg

Pediatric :

• SYS 40 ~ 220mmHg
• DIA 10 ~ 160mmHg
• MEAN 20 ~ 170mmHg

Neonatal :

• SYS 40 ~ 135mmHg
• DIA 10 ~ 100mmHg
• MEAN 20 ~ 110mmHg

Static pressure measurement

Range: 0 ~ 300mmHg

• Accuracy: ± 3mmHg
• Resolution: 1mmHg Accuracy:
• Max. Mean Error: ± 5mmHg
• Max. Standard Deviation: 8mmHg

Overpressure protection:

• Adult 300mmHg
• Pediatric 240mmHg
• Neonatal 150mmHg

SPO2 :

• Measurement range: 0 ~ 100%
• Resolution: 1%
• Accuracy: 70% ~ 100% ± 2%
• 40% ~ 69% ± 3%

Environment :

Operating environment :

• Temperature: 0 ~ 40 ℃
• Humidity: 15% ~ 80%
• Pressure: 86.0 kPa ~ 106.0kPa

Transport and Storage environment :

• Temperature: -20 ~ 55 ℃
• Humidity: 10% ~ 90%
• Pressure: 86.0 kPa ~ 106.0kPa
